Welding Gauge Bridge Cam Caliper Type WGU08

The Bridge Cam Welding Gauge, model WGU-8M, is a versatile tool designed to support thorough visual inspections of welds. This gauge allows for accurate measurement of multiple critical welding parameters, including depth of undercut, butt weld reinforcement height, fillet weld leg length, and weld preparation angle. With the addition of a vernier caliper, this model provides enhanced precision, making it easy to obtain reliable measurements in both inches and millimeters. Constructed from high-quality stainless steel, the WGU-8M is durable, corrosion-resistant, and suitable for industrial environments, making it a valuable tool for welders, inspectors, and quality control teams.

Key Features:

• Comprehensive Measurements: Measures undercut depth, butt weld reinforcement height, fillet weld leg length, and weld preparation angle
• Precision Vernier Caliper: Provides additional caliper feature to measure pipe, plate or welding wire thicknesses.
• Dual-Scale Readings: Displays measurements in millimeters
• Durable Construction: Made from high-grade stainless steel for longevity and resistance to wear and corrosion
• Portable Design: Compact and lightweight, ideal for on-site inspections and easy storage in toolkits

Specifications:

• Model Number: WGU-8M
• Material: Premium stainless steel
• Measurement Functions:
  • Undercut Depth: For accurate assessment of surface imperfections
  • Butt Weld Reinforcement Height: Ensures weld height meets structural standards
  • Fillet Leg Length: Measures actual leg length of fillet welds
  • Weld Preparation Angle: Verifies bevel angles for proper joint setup
• Measurement Range: Dual scales in inches and millimeters
• Applications: Suitable for welding inspection, fabrication, quality control, and industrial inspection

Package Includes:

• 1 x Bridge Cam Welding Gauge WGU-8M with Vernier Caliper

Enhance your welding inspection capabilities with the Bridge Cam Welding Gauge WGU-8M, equipped with a vernier caliper for high-precision measurements. Ensure that every weld meets quality and safety standards with this essential inspection tool.
