PH Meter PH/ORP-120

TOMLIN pH/ORP Meter (Model PH/ORP-120)

Description:
The TOMLIN pH/ORP Meter is a versatile and advanced device designed for various applications, including water treatment, galvanic decontamination, chemical processing, food processing, and clean or wastewater measurement, as well as neutralization processes. This instrument ensures accurate pH and ORP measurements, offering features tailored for industrial and laboratory environments.

Applications:

• Water Treatment: Ideal for monitoring and maintaining water quality.
• Chemical Processing: Ensures precision in critical processes.
• Food Processing: Verifies pH levels for safety and compliance.
• Wastewater Measurement: Monitors pH and ORP for environmental compliance.
• Neutralization Processes: Supports accuracy in balancing chemical reactions.

Features:

• Backlight Display: Provides clear visibility of readings, even in low-light conditions.
• Buzzer Sound Reminder: Alerts the user when a reading is complete.
• Manual/Auto Power Off: Saves battery life with automatic or manual shutdown options.
• Low Battery Indicator: Alerts users when battery power is low.
• Real-Time Measurement Transmission: Transmits data in real-time for continuous monitoring.
• Computer Connection: Connects to a computer for data analysis and storage.

Specifications:

Display: LCD
Range: 014pH/1mV, -10001000mV
Accuracy: 0.01pH, 1mV
Output: Optional DC 4-20 mA, Max. Load 1k
Calibration: 2 Points
Environment: 060°C (32°F140°F)
Power Supply: 4 x 1.5V AAA (UM-4) batteries
Size: 145 x 65 x 27 mm (5.7 x 2.6 x 1.1 inches)
Weight (Without Battery): 220 g (7.76 oz)

Standard Accessories:

• Main Unit
• Sensor
• Carrying Case

Optional Accessories:

• USB Data Cable (wired output)
• Bluetooth Adapter (wireless output)

Alternative Names for Search Optimization:

• Digital pH Meter with ORP Function
• Portable pH/ORP Analyzer
• Industrial pH Testing Device
• Laboratory pH and ORP Tester

Downloads

PDF Specification Sheet - Download Here
